Whether in the studio or on location, the Nanlux Evoke 2400B Bi-Color LED Monolight is a versatile and robust lighting solution, bringing excellent color rendering and flexibility for professionals in photography and filmmaking. It offers a wide color temperature range from 2700 to 6500K with a high CRI of 96 and TLCI of 97, ensuring accurate color rendering, while the green and magenta adjustments ensure perfect color tuning. The light's brightness can be finely adjusted from 0 to 100% with various dimming curves like linear and S-curve for consistent color output. Compact at 16.8 x 12.5 x 10.4", this monolight delivers a strong output of 41,910 lux at 3m. It features flexible control options, including DMX/RDM, wired DMX, and wireless controls through NANLINK, LumenRadio, or Bluetooth. The Evoke 2400B is designed for both studio and location use, with an IP55 rating for weather resistance, and includes a 45° reflector, an adjustable yoke, a 7.5m DC cable, and a super clamp.
2700K-6500K Wide CCT Range - From Sunrise to Daylight to Sunset
CRI: Average 96
TLCI: Average 97
| Item Type |
1 x LED Monolight |
| Included Light Modifier |
1 x Reflector |
| Included Storage Case |
No |
| Color Temperature |
2700 to 6500K |
| Color Modes |
Daylight, Tungsten |
| Color Accuracy Standard |
CRI 96 |
| Dimming |
Built-In Dimmer |
| Cooling System |
No |
| Beam Angle |
100° |
Connectivity
| Wireless Remote Control Type |
Art-Net |
| Mobile App Compatible |
Yes: Android & iOS |
| Wireless Channels |
No |
| Wireless Groups |
No |
| Wireless Frequency |
2.4 GHz |
Power & I/O
| AC Input Power |
100 to 240 VAC, 50 / 60 Hz at 26 A |
| DC Input Power |
48 VDC at 26 A |
Mounting
| Yoke Type |
Manually-Operated Yoke |
Environmental
| Environmental Protection |
Dust/Water-Resistant (IP55) |
General
| Display |
No |
| Dimensions |
42.7 x 31.8 x 26.4 cm (Fixture) |
| Weight |
15 kg |
LumenRadio TimoTwo
TimoTwo's both transmitting and receiving functions makes connection with other fixtures easy and stable.
NANLINK APP
Connects to NANLINK lighting control system via built-in 2.4G or Bluetooth to offer accurate and professional control at your fingertips.
DMX/RDM
Wire connects to DMX console via the on-board 5-pin XLR port to achieve stable and reliable control.
Wire Control
Connects to wire controller via the port on lamp head to provide an alternative solution for accurate control on set.
High Speed Mode
Heat dissipation boosted in high speed mode to meet the shooting requirements under high temperature environment.
Low Speed Mode
Limit the noise level within acceptable range for recording on set while discharging heat effectively. Maximum output is 50% in low speed mode.
Off Mode
Fan shut down to minimize the noise level for an optimal sound environment. Maximum output is 10% in off mode.
Quick release super clamp and offset Yoke come as standard. Secures the power supply tight on light stand & truss and facilitates quick swapping of lamp head respectively. New offset yoke design with 15° for greater range of tilting while using soft boxes and other light shaping accessories, all improvements are for fast-paced production on set.
Nanlux Evoke 2400B - NL mount
Whether in the studio or on location, the Nanlux Evoke 2400B Bi-Color LED Monolight is a versatile and robust lighting solution, bringing excellent color rendering and flexibility for professionals in photography and filmmaking. It offers a wide color temperature range from 2700 to 6500K with a high CRI of 96 and TLCI of 97, ensuring accurate color rendering, while the green and magenta adjustments ensure perfect color tuning. The light's brightness can be finely adjusted from 0 to 100% with various dimming curves like linear and S-curve for consistent color output. Compact at 16.8 x 12.5 x 10.4", this monolight delivers a strong output of 41,910 lux at 3m. It features flexible control options, including DMX/RDM, wired DMX, and wireless controls through NANLINK, LumenRadio, or Bluetooth. The Evoke 2400B is designed for both studio and location use, with an IP55 rating for weather resistance, and includes a 45° reflector, an adjustable yoke, a 7.5m DC cable, and a super clamp.
2700K-6500K Wide CCT Range - From Sunrise to Daylight to Sunset
CRI: Average 96
TLCI: Average 97
| Item Type |
1 x LED Monolight |
| Included Light Modifier |
1 x Reflector |
| Included Storage Case |
No |
| Color Temperature |
2700 to 6500K |
| Color Modes |
Daylight, Tungsten |
| Color Accuracy Standard |
CRI 96 |
| Dimming |
Built-In Dimmer |
| Cooling System |
No |
| Beam Angle |
100° |
Connectivity
| Wireless Remote Control Type |
Art-Net |
| Mobile App Compatible |
Yes: Android & iOS |
| Wireless Channels |
No |
| Wireless Groups |
No |
| Wireless Frequency |
2.4 GHz |
Power & I/O
| AC Input Power |
100 to 240 VAC, 50 / 60 Hz at 26 A |
| DC Input Power |
48 VDC at 26 A |
Mounting
| Yoke Type |
Manually-Operated Yoke |
Environmental
| Environmental Protection |
Dust/Water-Resistant (IP55) |
General
| Display |
No |
| Dimensions |
42.7 x 31.8 x 26.4 cm (Fixture) |
| Weight |
15 kg |
LumenRadio TimoTwo
TimoTwo's both transmitting and receiving functions makes connection with other fixtures easy and stable.
NANLINK APP
Connects to NANLINK lighting control system via built-in 2.4G or Bluetooth to offer accurate and professional control at your fingertips.
DMX/RDM
Wire connects to DMX console via the on-board 5-pin XLR port to achieve stable and reliable control.
Wire Control
Connects to wire controller via the port on lamp head to provide an alternative solution for accurate control on set.
High Speed Mode
Heat dissipation boosted in high speed mode to meet the shooting requirements under high temperature environment.
Low Speed Mode
Limit the noise level within acceptable range for recording on set while discharging heat effectively. Maximum output is 50% in low speed mode.
Off Mode
Fan shut down to minimize the noise level for an optimal sound environment. Maximum output is 10% in off mode.
Quick release super clamp and offset Yoke come as standard. Secures the power supply tight on light stand & truss and facilitates quick swapping of lamp head respectively. New offset yoke design with 15° for greater range of tilting while using soft boxes and other light shaping accessories, all improvements are for fast-paced production on set.
Included in the box
1x Lamphead w/ Cap; 1x Offset Yoke; 1x Ballast w/ Mount; 1x Powercord; 1x 16A Blue -> Schuko Adapter; 1x Signal Cable 5m; 1x Remonte Control; 1x Reflector 45°, 1x Rolling Hardcase.
